MobiiConnect 4G Manual 10TipClick Change to customise your Wi-Fi network name (SSID).Web Management - Information tab You can view the device informat

MobiiConnect 4G Manual 11Information > Statistics Select Statistics from the left-hand column to view your data usage on this page. Please note th

MobiiConnect 4G Manual 12Information > Data Limit Settings Select Data Limit Settings from the left-hand column to set data usage limits and remind

MobiiConnect 4G Manual 13Web Management - SD Card tab If you insert a compatible microSD™ memory card in your MobiiConnect 4G, you can use it as an e

MobiiConnect 4G Manual 14Web Management – SMS tabWeb Management – Phonebook tabWeb Management - Settings tab iiNet Group Mobile Broadband services do

MobiiConnect 4G Manual 15Settings > Network Settings > Dial up Settings The default setting for WAN Connection Mode is Automatic. If set to Ma

MobiiConnect 4G Manual 16Settings > Network Settings > Network selection Network Selection is set to Automatic by default. This is recommended

MobiiConnect 4G Manual 17Settings > Network Settings > APN The MobiiConnect 4G is preconfigured with default APN for iiNet (Westnet also uses t

MobiiConnect 4G Manual 18Settings > Wi-Fi Settings > Basic Settings Set Wi-Fi Switch to Enable or Disable to control the availability of your Mo

MobiiConnect 4G Manual 19Settings > Wi-Fi Settings > Advanced Settings On this page you can manually configure your advanced Wi-Fi settings.

MobiiConnect 4G Manual 2MobiiConnect 4G Overview 4LED indicators guide 5Manually running the installation software 6Logging in to the Web Management p

MobiiConnect 4G Manual 20Settings > WPSWPS stands for “Wi-Fi Protected Setup”. Follow the steps below to connect WPS-compatible devices to the Wi-F

MobiiConnect 4G Manual 21Settings > Device settings > Account Management WPS stands for “Wi-Fi Protected Setup”. Follow the steps below to conn

MobiiConnect 4G Manual 22Settings > Device settings > ResetYou can use this page to action a Factory Reset of your MobiiConnect 4G without using

MobiiConnect 4G Manual 23Settings > Device settings > Power Save You can adjust the Power Saving settings on this page. By default, Wi-Fi Perf

MobiiConnect 4G Manual 24Settings > Device settings > Update Management You can check for MobiiConnect 4G software updates on this page. Press

MobiiConnect 4G Manual 25Settings > Firewall > Port Filtering You can adjust Port Filtering setting on this page. Select Enable to turn on Port

MobiiConnect 4G Manual 26Settings > Firewall > Port Mapping You can customise Port Mapping setting on this page. Port mapping can be used to a

MobiiConnect 4G Manual 27Settings > Firewall > System SecuritySettings > DMZ You can enable Remote Management via the WAN on this page. You

MobiiConnect 4G Manual 28Settings > Firewall > Router Settings On this page you can see the Router settings. For use with an iiNet Group Mobi

MobiiConnect 4G Manual 29Settings > Firewall > Internet Wi-Fi On this page you can enable the MobiiConnect 4G Wi-Fi to connect to another Wi-Fi

MobiiConnect 4G Manual 3Settings > Device settings > PIN Management 21Settings > Device settings > Reset 23Settings > Device settings &

MobiiConnect 4G Manual 30Using the External Antenna Ports The MobiiConnect 4G only supports TS9 connection external Wi-Fi antennas that are suitable

MobiiConnect 4G Manual 31How to Factory Reset the MobiiConnect 4GA factory reset is useful if you have forgotten your custom passwords and can no long

MobiiConnect 4G Manual 32Uninstalling the MobiiConnect 4G softwareWindows Start Menu > All Programs > MobiiConnect 4G > UninstallMac OSX Ap

MobiiConnect 4G Manual 33Precautions and Safety Information Some electronic devices are susceptible to electromagnetic interference. The MobiiConnect

MobiiConnect 4G Manual 34RF Safety InformationRadio Frequency EnergyDeclaration of Conformity - SARThe MobiiConnect 4G has internal antennas. For opti

MobiiConnect 4G Manual 35Technical SpecificationsNetwork compatibilityLTE 1800, 2600 MHzUMTS 900, 2100 MHz GSM 900, 1800, 1900 MHzDimensions 95 x 30 x

MobiiConnect 4G Manual 36Supported Operating systemsWindows 8, 7, XP SP3, VistaMAC OS X 10.5 and aboveWi-Fi802.11a/b/g/n (2*2 11n features), WPA, WPA-

Copyright © 2014. All rights reserved.No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, el

If you have any issues with your MobiiConnect 4G or technology just isn’t your strong point, you can always call our friendly Support Team for a hand.

MobiiConnect 4G Manual 4MobiiConnect 4G Overview1. USB plug for computer, AC adapter or car charger adapter2. Reset button3. microSD™ memory card

MobiiConnect 4G Manual 5LED indicators guideWi-Fi Status Light MeaningNot Lit Wi-Fi is Off. Use Web Management page to turn back onBlue solid WPS (Wi-

MobiiConnect 4G Manual 6Manually running the installation softwareThe installation software is pre-loaded onto your USB modem. Typically, it will run

MobiiConnect 4G Manual 7Logging in to the Web Management page1. Open your internet browser and go to http://192.168.0.1 2. Log in with the default p

MobiiConnect 4G Manual 8Web Management - Status iconsYou’ll see these icons in the upper right-hand corner of the Web Management page.Status Icon Mean

MobiiConnect 4G Manual 9Web Management Home Page The Disconnect button on the Home page will take MobiiConnect 4G offline.
